Delta HMPE Round Sling 3000

Rated at 30,000 lbs in a vertical hitch and 60,000 lbs in a basket configuration, the Delta HMPE Round Sling 3000 from HMPE Warehouse is built for mid-to-heavy industrial lifting tasks. This sling leverages the extraordinary tensile properties of ultra-high-molecular-weight polyethylene fiber to deliver wire-rope-class load ratings in a package that weighs a fraction of its steel equivalent.

The dual-layer construction — UHMWPE core with a protective polyester outer sleeve — guards the load-bearing fibers against abrasion, cutting, and environmental degradation while keeping the sling supple enough to conform to irregular load shapes. That flexibility translates to better load control and reduced risk of surface marring on polished or coated components.

At 0.75 lbs per foot with a 3-inch body width, the sling is manageable for single-rigger handling in most situations, speeding up rigging time and reducing crew fatigue over the course of a shift. The Delta HMPE Round Sling 3000 is an excellent fit for power generation, offshore platform maintenance, bridge construction, and any application where load security and operator efficiency are priorities.

Working Load Limits (WLL)

• Vertical WLL: 30,000 lbs / 13.61 Metric Tonnes (5:1 safety factor)
• Choker WLL: 24,000 lbs / 10.89 Metric Tonnes (5:1 safety factor)
• Basket WLL: 60,000 lbs / 27.22 Metric Tonnes (5:1 safety factor)
• Basket WLL (60°): 51,960 lbs (5:1 safety factor)
• Basket WLL (45°): 42,420 lbs (5:1 safety factor)

Every rating carries a 5:1 design factor, meaning the sling's minimum break strength is five times the stated working load limit — a critical margin of safety for repetitive lifting operations.

Specifications

• Core Material: UHMWPE (Ultra-High-Molecular-Weight Polyethylene)
• Cover Material: Polyester
• Weight: 0.75 lbs/ft
• Body Width: 3 inches
• Design Factor: 5:1
