Delta HMPE Round Sling 15000

The Delta HMPE Round Sling 15000 from HMPE Warehouse sits near the top of the capacity range with a 150,000 lb vertical WLL and a 300,000 lb basket hitch rating — loads measured in the hundreds of tons that are typical of major offshore installations, heavy civil infrastructure, and large-scale industrial construction.

At 3.50 lbs per foot, this sling weighs a small fraction of the wire rope assemblies it can replace, creating a measurable advantage in net crane capacity and rigging efficiency that compounds across every lift on a project. The 7-inch body width creates a wide bearing footprint that protects load surfaces and distributes sling tension across the maximum possible contact area.

Inside, the UHMWPE core fibers maintain their rated strength even after prolonged exposure to moisture, making the sling ideal for marine terminals, floating production systems, and wet-environment construction. The polyester cover provides a durable first layer of protection against abrasion, cuts, and UV radiation. The Delta HMPE Round Sling 15000 is the solution for lift engineers who need the highest capacity available in a synthetic round sling format.

Working Load Limits (WLL)

• Vertical WLL: 150,000 lbs / 68.04 Metric Tonnes (5:1 safety factor)
• Choker WLL: 120,000 lbs / 54.43 Metric Tonnes (5:1 safety factor)
• Basket WLL: 300,000 lbs / 136.08 Metric Tonnes (5:1 safety factor)
• Basket WLL (60°): 259,800 lbs (5:1 safety factor)
• Basket WLL (45°): 212,100 lbs (5:1 safety factor)

Every rating carries a 5:1 design factor, meaning the sling's minimum break strength is five times the stated working load limit — a critical margin of safety for repetitive lifting operations.

Specifications

• Core Material: UHMWPE (Ultra-High-Molecular-Weight Polyethylene)
• Cover Material: Polyester
• Weight: 3.50 lbs/ft
• Body Width: 7 inches
• Design Factor: 5:1
