Delta HMPE Round Sling 10000

Breaking the six-figure barrier, the Delta HMPE Round Sling 10000 from HMPE Warehouse delivers a vertical WLL of 100,000 lbs and a basket hitch capacity of 200,000 lbs — performance that places it firmly in the category of heavy-lift rigging hardware used on major capital projects.

What makes this sling remarkable is that it achieves these ratings at just 2.00 lbs per foot, offering a transformative weight advantage over the multi-ton wire rope slings traditionally used at this capacity level.

The core technology is ultra-high-molecular-weight polyethylene fiber, which provides pound-for-pound tensile strength that rivals steel while being buoyant, chemically inert, and resistant to fatigue from repeated load cycles. The polyester tubular cover protects the load-bearing core from field hazards and gives inspectors a clear visual reference for assessing sling condition. With a 5-inch body width, the sling creates a broad contact footprint that minimizes bearing pressure on the load. The Delta HMPE Round Sling 10000 is designed for the most demanding applications in the lifting industry — including offshore heavy lifts, refinery turnarounds, bridge segment installation, and large-scale industrial plant construction.

Working Load Limits (WLL)

• Vertical WLL: 100,000 lbs / 45.36 Metric Tonnes (5:1 safety factor)
• Choker WLL: 80,000 lbs / 36.29 Metric Tonnes (5:1 safety factor)
• Basket WLL: 200,000 lbs / 90.72 Metric Tonnes (5:1 safety factor)
• Basket WLL (60°): 173,200 lbs (5:1 safety factor)
• Basket WLL (45°): 141,400 lbs (5:1 safety factor)

Every rating carries a 5:1 design factor, meaning the sling's minimum break strength is five times the stated working load limit — a critical margin of safety for repetitive lifting operations.

Specifications

• Core Material: UHMWPE (Ultra-High-Molecular-Weight Polyethylene)
• Cover Material: Polyester
• Weight: 2.00 lbs/ft
• Body Width: 5 inches
• Design Factor: 5:1
